Emergency Shelter Kit

Woven high-density polyethylene (HDPE) black fibres fabric laminated on both sides with low-density polyethylene (LDPE) coating. Reinforced with 6 bands of 7.5cm width made of woven black HDPE fibres fabric and coated outside

Minimum 50DaN and 15% to 25% elongation in warp and weft outside of reinforcement bands under ISO 1421. Minimum 70DaN inside the reinforcement bands as per ISO 1421 plus the additional procedure

Minimum 10DaN under ISO 4674 (A”) outside of the reinforcement bands

Only one welding allowed, in the middle of the sheet, length wise. Minimum resistance is 80% of the original tarpaulin tensile strength in weft under ISO 1421 plus additional procedure

Maximum 5% loss on original tarpaulin tensile strength under ISO 1421 after 1500 hours UV under ASTM G53/94 (UVB 313 nm peak), to be tested outside and inside the reinforcement bands

Temperature resistance from –20 to +80ºC

Water, rot, soil and fauna resistant. Long outdoor use life in all climates.

Flash point above 200ºC

White sun reflective both sides, grey bands. Inner black fibres to ensure opacity

Located in the reinforcing bands at the edge of the sheet (sides only), with spacing of maximum 100cm (± 5cm). Can withstand constant load of 50 kgs for a minimum of 1 minute without damaging the plastic sheeting

2 years minimum

Shelter Kit items are packaged by folding the items inside of the plastic sheeting. Each completed kits are packed in a poly-bag with customized markings. Completed kit consists of 2x plastic sheets measuring 4 m x 7 m each / 2x long ropes measuring 24 m each / 1 x laminated instructions sheet.

Peg & Pole Kit: 2x pole, 4x TR pegs, 2x base plates
